FX-77GII

Specifications FX-77GII

Model No.
AH00239

Input Methods
Infrared and Ultrasonic methods

Interface to Computer
USB 1.1 / USB 2.0

Effective Screen Size
62’’ (W) x 46’’ (H)
1,573mm (W) x 1,180mm (H)

IR Wavelength
880nm

Ultrasonic Frequency
40kHz

Sampling Rate
Approximately 66 points/s

Resolution
Approximately 195.4lpi

Accuracy
Approximately ±0.06 inches, (±1.5mm)

Board/Surface Material
Lauan wood + EPS (core), Colour steel boards
(surface)

Operating Specification
60 - 95 Fahrenheit (16 – 35 Celsius), 20 – 80% Humidity

Power consumption
5V, 100mA

Dimensions
70.6’’ (W) x 48.0’’ (H) x 2.7’’ (D)
1,793mm (W) x 1,220mm (H) x 68mm (D)

Weight (main unit)
Approx. 15kg

Packing dimension (main unit)
74.8’’ (W) x 54.7’’ (H) x 4.3’’ (D)
1,900mm (W) x 1,390mm (H) x 110mm (D)

Packing weight (main unit)
Approx. 25kg

Certificates
VCCI ClassB, FCC ClassB, CE, ROHS

Electronic pen
Power supply
AA

Expected battery life
Approx. 90 hours continuous use (alkaline battery)

System Requirements
based on StarBoard Software 8.13

Computers
CPU: Pentium 4 1.8GHz; RAM: 512MB; HDD
200MB of free space; Internet Explorer 6/7/8;
Microsoft Office 2002/2003/2007; Adobe
Acrobat Reader 5.05; Adobe Reader 6/7/8/9;
Microsoft Visio 2002/2003/2007; Microsoft
Project 2002/2003; Microsoft DirectX 9.0c or
higher; Window Media Encoder 9.0;
Windows Operating System
Microsoft Windows 2000, Microsoft Windows
XP(32bits), Microsoft Windows Vista(32bits),
Microsoft Windows 7(32bits) (latest service
pack recommended)

Interactive White Boards Wireless Tablets LCD Projectors

StarBoard | FX-77GII | Interactive White Board

Affordable Solution
The FX-77GII interactive whiteboard enables static presentations to be turned into dynamic activities. Simply connect the FX-77GII board to a computer and LCD projector and control the board with the easy-to-use StarBoard Software - all in a matter of minutes! All electronics on the FX-77GII are contained in a fieldreplaceable digitiser. This provides an electronic-free surface for durable use.

Electronic Pen Control
FX-77GII interactive whiteboard utilises a wireless 2-button electronic pen with full mouse and hover functions for computer operations.

Durable Electronic-free Surface
Optimized durability which ensures the board remains fully operational even with minor dents and scratches to the surface.

Shortcut Buttons
12 shortcut customisable buttons for easy access to the StarBoard Software functionalities currently in use.

Flexibility of Use
Use it as a normal whiteboard – attach magnets to the board’s surface or write with markers without any risk of damage to the interactive features.
