Specifications CPX1
OPTICAL
LCD Panel: 0.63"P-Si TFT x 3
Resolution XGA: 1024 dots x 768 lines
Number of Colour: 8bit / colour, 16.7Mcolours
Brightness: 2000lm Normal Mode
1600lm Whisper Mode
Contrast Ratio: 500:1
Lamp: UHB 160W
Lamp Life @ whisper: 3000hrs
Lens: F1.8~1.9 x1.2 Optical Zoom (f=16.4~19.7 mm), Manual Focus
Keystone: 6:1upward shift, fixed
Digital Keystone: Auto V keystone
Diagonal Display: Size 30~300 inches
(60" @ 1.5m)
Computer Compatibility: IBM Compatible VGA, SVGA XGA, SXGA / SXGA+,UXGA Compressed, MAC 16"
Video Compatibility: NTSC / PAL / SECAM / PAL-M,N / NTSC4.43
SDTV: 525i(480i), 525p(480p), 625i(576i)
HDTV: 750p (720p@60Hz), 1125i(1080i@50 / 60Hz)
Audio Speakers: 1.0 W x 1
CONNECTIONS
Audio Input: 1 x Stereo Mini jack
Video Input: 1 x Composite
1 x S-Video jack
1 x Component (shared with D-sub1)
Data Input: 2 x 15-pin Mini D-sub
Control and Mouse: USB type B x 1 for mouse control
NO RS-232C
USB type: A x1 for PC-less presentation •
Audio Output: 1 x Stereo Mini jack
Physical
Weight: 1.7kg (3.8lbs)
Size: (W x H x D) 274 x 59 x 205 mm
(excluding feet and extrusions)
Miscellaneous
Lamp Indicator Light, Power Indicator Light, Temp Indicator Light, Ceiling Mount Image, Rear Projection Image
Accessories Power Cord, RGB Cable (2m), Wireless Remote Control Unit, "AA" Batteries (x 2), Soft Case, Rivet, Strap, Lens Cap, Filter Cover (for bottom-up use), Operating Guide (14 Languages), Safety Instructions (15 Languages on CD-ROM), Users Manual (14 Languages: English, French, Spanish, German, Italian, Norwegian, Dutch, Portuguese, Simplified Chinese, Korean, Swedish, Russian, Finnish, Polish)
POWER
Voltage: 100-120V / 220-240V
auto switching
Noise: 35dB Normal Mode
29dB Whisper Mode
Agency Certifications: CE approval, EN61000-3-2, EN61000-3-3, EN55022, EN55024, EN60950, Low voltage directive, WEEE
Features
ASPECT selection
For Video: 4:3 / 16:9 / 14:9 / Small
For Data: Normal / 4:3 / 16:9 / Small
Vertical Digital Keystone Correction: ±30degrees (Note: Input signal is XGA @ 60Hz, Zoom position is Wide max.), Auto Vertical Digital Keystone Correction: ±30degrees, Mirror Reverse Image, Up-side Down Image, Freeze, Magnify, Blank, Digital Gamma Correction, Color temperature Adjustment, Picture mode (Normal, Cinema, Dynamic, Board (Black), Board (Green), Whiteboard), Progressive (Video / S-Video signal, Component video of 525i(480i), 625i(576i)), 2-3 Pull Down for NTSC, Video noise reduction, Overscan (Video, S-Video, Component signal), Resolution setting, Frame Lock, Audio ports assign, Source naming, Quick start (3 Seconds), Instant off, Auto signal search, MyScreen PIN Lock, Transition detector, PIN Security Lock, 17 Languages OSD (English, French, German, Spanish, Italian, Norwegian,Dutch, Japanese, Portuguese, Simplified Chinese, Traditional Chinese, Korean, Swedish, Russian, Finnish, Polish, Turkey), PC Less Presentation
Customisation MyScreen, My Memory, My Button Back to Top > |
